140CPS12420

Power Supply Module Modicon Quantum – 115 V/230 V AC – redundant
Main
range of product
Modicon Quantum automation platform
product or component type
Power supply module
power supply type
Redundant
Complementary
input voltage
230 V AC 170…276 V
115 V AC 93…138 V 47…63 Hz
input current
1100 mA 115 V
600 mA 230 V
inrush current
19 A 230 V
38 A 115 V
rated power in VA
130 VA
associated fuse rating
2 A slow-blow
harmonic distortion
<= 10 % of fundamental rms value output voltage 5.1 V DC power supply output current 11 A 140 °F (60 °C) standalone 10 A 140 °F (60 °C) redundant output overvoltage protection Internal output overload protection Internal power dissipation 6 + (1.5 x Iout) where Iout is in A alarm output 1 NC 6 A 220 V power supply fault local signalling 1 LED green power (PWR OK) marking CE module format Standard product weight 1.43 lb(US) (0.65 kg) Environment standards UL 508 CSA C22.2 No 142 product certifications CUL resistance to electrostatic discharge 4 kV contact conforming to IEC 801-2 8 kV on air conforming to IEC 801-2 resistance to electromagnetic fields 9.14 V/yd (10 V/m) 80…2000 MHz conforming to IEC 801-3 ambient air temperature for operation 32…140 °F (0…60 °C) ambient air temperature for storage -40…185 °F (-40…85 °C) relative humidity 95 % without condensation operating altitude <= 16404.2 ft (5000 m)
