| Range of product | Modicon Quantum automation platform |
|---|---|
| Product or component type | Power supply module |
| Power supply type | Redundant |
| Input voltage | 115 V (93…138 V) AC 47…63 Hz 230 V (170…276 V) AC |
|---|---|
| Input current | 1100 mA at 115 V 600 mA at 230 V |
| Inrush current | 19 A 230 V 38 A 115 V |
| rated power in VA | 130 VA |
| Associated fuse rating | 2 A, slow-blow |
| Harmonic distortion | <= 10 % of fundamental rms value |
| Output voltage | 5.1 V DC |
| Power supply output current | 8 A 60 °C redundant |
| Output overvoltage protection | Internal |
| Output overload protection | Internal |
| Power dissipation | 6 + (1.5 x Iout) where Iout is in A |
| Local signalling | 1 LED (green) for power (PWR OK) |
| Marking | CE |
| Module format | Standard |
| Net weight | 0.65 kg |
| Standards | UL 508 CSA C22.2 No 142 |
|---|---|
| Product certifications | cUL FM Class 1 Division 2 |
| Resistance to electrostatic discharge | 4 kV contact conforming to IEC 801-2 8 kV on air conforming to IEC 801-2 |
| Resistance to electromagnetic fields | 10 V/m 80…2000 MHz conforming to IEC 801-3 |
| Ambient air temperature for operation | 0…60 °C |
| Ambient air temperature for storage | -40…85 °C |
| Relative humidity | 95 % without condensation |
| Operating altitude | <= 5000 m |
| Unit Type of Package 1 | PCE |
|---|---|
| Number of Units in Package 1 | 1 |
| Package 1 Height | 5.0 cm |
| Package 1 Width | 16.5 cm |
| Package 1 Length | 31.5 cm |
| Package 1 Weight | 778.0 g |
